| Code Word | AWG/Kcmil | Al (mm²) | AW (mm²) | Total (mm²) | Stranding Al | Stranding AW | Overall Dia. (mm) | Unit Weight (kg/km) | Rated Strength (kN) | El. Resistance (Ω/km) |
|---|---|---|---|---|---|---|---|---|---|---|
| BUNTING | 1192,5 | 605,8 | 41,9 | 647,6 | 45×4,14 | 7×2,76 | 33,12 | 1948 | 139,0 | 0,047 |
| CRACKLE | 1192,5 | 602,8 | 76,9 | 679,7 | 54×3,77 | 19×2,27 | 33,97 | 2187 | 179,0 | 0,046 |
| BITTERN | 1272,0 | 644,4 | 44,7 | 689,1 | 45×4,27 | 7×2,85 | 34,17 | 2077 | 149,0 | 0,044 |
| PHEASANT | 1272,0 | 645,4 | 81,7 | 726,8 | 54×3,90 | 19×2,34 | 35,10 | 2333 | 189,0 | 0,043 |
| SKYLARK | 1272,0 | 645,0 | 18,0 | 664,0 | 36×4,78 | 1×4,78 | 33,42 | 1893 | 114,0 | 0,044 |
| DIPPER | 1351,5 | 684,2 | 46,9 | 731,1 | 45×4,40 | 7×2,92 | 35,16 | 2207 | 158,0 | 0,041 |
| MARTIN | 1351,5 | 685,4 | 86,7 | 772,1 | 54×4,02 | 19×2,41 | 36,17 | 2478 | 200,0 | 0,041 |
| BOBOLINK | 1431,0 | 725,3 | 50,1 | 775,4 | 45×4,53 | 7×3,02 | 36,24 | 2337 | 167,0 | 0,039 |
| PLOVER | 1431,0 | 726,9 | 91,8 | 818,7 | 54×4,14 | 19×2,48 | 37,24 | 2625 | 212,0 | 0,038 |
| NUTHACH | 1510,5 | 764,2 | 52,8 | 817,0 | 45×4,65 | 7×3,10 | 37,20 | 2467 | 176,0 | 0,037 |
| PARROT | 1510,5 | 766,1 | 97,0 | 863,1 | 54×4,25 | 19×2,55 | 38,25 | 2788 | 224,0 | 0,036 |
| LAPWING | 1590,0 | 804,2 | 55,6 | 859,7 | 45×4,77 | 7×3,18 | 38,16 | 2598 | 186,0 | 0,035 |
| FALCON | 1590,0 | 806,2 | 102,4 | 908,7 | 54×4,36 | 19×2,62 | 39,26 | 2917 | 236,0 | 0,035 |
| CHUKAR | 1780,0 | 903,2 | 73,5 | 976,7 | 84×3,70 | 19×2,22 | 42,70 | 2995 | 220,0 | 0,031 |
| BLUEBIRD | 2156,0 | 1092,8 | 88,8 | 1181,6 | 84×4,07 | 19×2,44 | 44,76 | 3626 | 262,0 | 0,026 |
| KIWI | 2167,0 | 1099,8 | 47,5 | 1147,3 | 72×4,41 | 7×2,94 | 44,10 | 3367 | 219,0 | 0,026 |
| THRASHER | 2312,0 | 1171,4 | 63,9 | 1235,3 | 76×4,43 | 19×2,07 | 45,79 | 3678 | 246,0 | 0,024 |
| GROUSE | 80,0 | 40,5 | 14,3 | 54,8 | 8×2,54 | 1×4,24 | 9,32 | 205 | 21,7 | 0,635 |
| PETREL | 101,8 | 51,6 | 30,1 | 81,7 | 12×2,34 | 7×2,24 | 11,71 | 342 | 44,1 | 0,469 |
| MINORCA | 110,8 | 56,1 | 32,8 | 88,9 | 12×2,44 | 7×2,44 | 12,22 | 372 | 48,0 | 0,431 |
| LEGHORN | 134,6 | 68,2 | 39,8 | 108,0 | 12×2,69 | 7×2,69 | 13,46 | 452 | 57,8 | 0,354 |
| GUINEA | 159,0 | 80,6 | 47,0 | 127,6 | 12×2,92 | 7×2,92 | 14,63 | 534 | 68,0 | 0,300 |
| DOTTEREL | 176,9 | 89,5 | 52,2 | 141,7 | 12×3,08 | 7×3,08 | 15,42 | 594 | 75,4 | 0,270 |
| DORKING | 190,8 | 96,7 | 56,4 | 153,1 | 12×3,20 | 7×3,20 | 16,03 | 641 | 81,3 | 0,250 |
| BRAHMA | 203,2 | 103,0 | 91,9 | 194,8 | 16×2,86 | 19×2,48 | 18,14 | 894 | 120,0 | 0,216 |
| COCHIN | 211,8 | 107,1 | 62,5 | 169,6 | 12×3,37 | 7×3,37 | 16,84 | 709 | 88,0 | 0,226 |
