| Code Number | Steel Ratio (%) | Cross Section Aluminium (mm²) | Cross Section SA1A (mm²) | Cross Section Total (mm²) | Stranding & Wire Diam. Aluminium | Stranding & Wire Diam. SA1A | Overall Diameter (mm) | Unit Weight (kg/km) | Rated Strength (kN) | Electrical Resistance AT 20°C (ohm/km) |
|---|---|---|---|---|---|---|---|---|---|---|
| 16 | 16,7 | 15 | 2,56 | 17,6 | 6X1,81 | 1X1,81 | 5,43 | 59,0 | 5,91 | 1,792 |
| 25 | 16,7 | 24 | 4,00 | 28,0 | 6X2,26 | 1X2,26 | 6,78 | 92,1 | 9,00 | 1,147 |
| 40 | 16,7 | 38 | 6,40 | 44,4 | 6X2,85 | 1X2,85 | 8,55 | 147,4 | 14,21 | 0,717 |
| 63 | 16,7 | 60 | 10,08 | 70,1 | 6X3,58 | 1X3,58 | 10,70 | 232,2 | 21,17 | 0,455 |
| 100 | 16,7 | 96 | 16,00 | 112,0 | 6X4,51 | 1X4,51 | 13,50 | 368,6 | 31,84 | 0,287 |
| 125 | 5,6 | 123 | 6,85 | 130,0 | 18X2,95 | 1X2,95 | 14,80 | 384,3 | 29,18 | 0,230 |
| 125 | 16,3 | 120 | 19,60 | 140,0 | 26X2,43 | 7X1,89 | 15,40 | 460,8 | 44,49 | 0,231 |
| 160 | 5,6 | 158 | 8,77 | 167,0 | 18X3,34 | 1X3,34 | 16,70 | 491,9 | 36,38 | 0,180 |
| 160 | 16,3 | 154 | 25,00 | 179,0 | 26X2,74 | 7X2,13 | 17,40 | 589,8 | 56,18 | 0,180 |
| 200 | 5,6 | 197 | 10,96 | 208,0 | 18X3,74 | 1X3,74 | 18,70 | 614,9 | 43,62 | 0,144 |
| 200 | 16,3 | 192 | 31,30 | 223,0 | 26X3,07 | 7X2,39 | 19,40 | 737,2 | 69,27 | 0,144 |
| 250 | 9,8 | 244 | 24,00 | 268,0 | 32X3,76 | 7X2,09 | 21,30 | 830,9 | 67,80 | 0,115 |
| 250 | 16,3 | 240 | 39,10 | 279,0 | 26X3,43 | 7X2,67 | 21,70 | 921,5 | 86,58 | 0,115 |
| 315 | 6,9 | 310 | 21,40 | 331,0 | 45X2,96 | 7X1,97 | 23,70 | 996,4 | 78,33 | 0,092 |
| 315 | 16,3 | 303 | 49,30 | 352,0 | 26X3,75 | 7X2,99 | 24,40 | 1161,1 | 107,58 | 0,092 |
| 400 | 6,9 | 393 | 27,20 | 420,0 | 45X3,34 | 7X2,22 | 26,70 | 1265,3 | 97,50 | 0,072 |
| 400 | 13,0 | 387 | 50,20 | 437,0 | 54X3,02 | 7X3,02 | 27,20 | 1402,9 | 124,20 | 0,072 |
| 450 | 6,9 | 442 | 40,60 | 483,0 | 45X3,54 | 7X2,36 | 28,30 | 1423,4 | 107,48 | 0,064 |
| 450 | 13,0 | 436 | 56,50 | 493,0 | 54X3,21 | 7X3,21 | 28,90 | 1578,2 | 139,72 | 0,064 |
| 500 | 6,9 | 492 | 34,00 | 526,0 | 45X3,73 | 7X2,49 | 29,80 | 1581,6 | 119,42 | 0,058 |
| 500 | 13,0 | 484 | 62,80 | 547,0 | 54X3,78 | 7X3,38 | 30,40 | 1753,6 | 153,99 | 0,058 |
| 560 | 6,9 | 550 | 38,10 | 588,0 | 45X3,95 | 7X2,63 | 31,60 | 1771,4 | 133,75 | 0,052 |
| 560 | 12,7 | 543 | 68,80 | 612,0 | 54X3,58 | 19X2,15 | 32,20 | 1956,3 | 169,36 | 0,052 |
| 630 | 6,9 | 619 | 42,80 | 662,0 | 45X4,19 | 7X2,79 | 33,50 | 1992,8 | 150,47 | 0,046 |
| 630 | 12,7 | 611 | 77,30 | 688,0 | 54X3,79 | 19X2,28 | 34,20 | 2200,9 | 190,52 | 0,046 |
| 710 | 6,9 | 698 | 48,30 | 476,0 | 45X4,44 | 7X2,96 | 35,60 | 2245,8 | 169,57 | 0,041 |
| 710 | 12,7 | 688 | 87,20 | 775,0 | 54X4,03 | 19X2,42 | 36,30 | 2480,3 | 214,72 | 0,041 |
| 800 | 4,3 | 791 | 34,20 | 825,0 | 72X3,74 | 7X2,49 | 37,40 | 2412,8 | 167,67 | 0,036 |
| 800 | 8,3 | 784 | 65,30 | 849,0 | 84X3,45 | 7X3,45 | 37,90 | 2598,9 | 206,37 | 0,036 |
| 800 | 12,7 | 775 | 98,20 | 873,0 | 54X4,28 | 19X2,57 | 38,50 | 2794,7 | 241,94 | 0,036 |
| 900 | 4,3 | 890 | 38,50 | 929,0 | 72X3,97 | 7X2,65 | 39,70 | 2714,4 | 188,63 | 0,032 |
| 900 | 8,3 | 882 | 73,50 | 956,0 | 84X3,66 | 7X3,66 | 40,20 | 2923,8 | 224,82 | 0,032 |
| 1000 | 4,3 | 989 | 42,70 | 1032,0 | 72X4,18 | 7X2,79 | 41,80 | 3016,0 | 209,59 | 0,029 |
| 1120 | 8,1 | 1098 | 89,40 | 1187,0 | 84X4,08 | 19X2,45 | 44,90 | 3628,4 | 282,88 | 0,026 |
| 1250 | 8,1 | 1225 | 99,80 | 1325,0 | 84X4,31 | 19X2,59 | 47,40 | 4049,5 | 315,72 | 0,023 |
| Code Word | AWG/Kcmil | Aluminium (mm²) | AW (mm²) | Total (mm²) | Alüminyum Tel Yapısı | AW Tel Yapısı | Çap (mm) | Ağırlık (kg/km) | Mukavemet (kN) | Direnç (Ω/km) |
|---|---|---|---|---|---|---|---|---|---|---|
| SWAN | 4.0 | 21.2 | 3.53 | 24.7 | 6x2.12 | 1x2.12 | 6.36 | 81 | 7.9 | 1.282 |
| SWANATE | 4.0 | 21.1 | 5.35 | 26.5 | 7x1.96 | 1x2.61 | 6.53 | 93 | 10.1 | 1.251 |
| SPARROW | 2.0 | 33.6 | 5.60 | 39.2 | 6x2.67 | 1x2.67 | 8.01 | 129 | 12.3 | 0.808 |
| SPARATE | 2.0 | 33.5 | 8.55 | 42.1 | 7x2.47 | 1x3.30 | 8.24 | 149 | 15.6 | 0.787 |
| ROBIN | 1.0 | 42.4 | 7.07 | 49.5 | 6x3.00 | 1x3.00 | 9.00 | 163 | 15.3 | 0.640 |
| RAVEN | 1/0 | 53.5 | 8.92 | 62.4 | 6x3.37 | 1x3.37 | 10.11 | 205 | 18.9 | 0.507 |
| QUAIL | 2/0 | 67.3 | 11.22 | 78.6 | 6x3.78 | 1x3.78 | 11.34 | 259 | 22.8 | 0.403 |
| PIGEON | 3/0 | 85.1 | 14.19 | 99.3 | 6x4.25 | 1x4.25 | 12.75 | 326 | 28.0 | 0.319 |
| PENGUIN | 4/0 | 107.2 | 17.87 | 125.1 | 6x4.77 | 1x4.77 | 14.31 | 411 | 34.2 | 0.253 |
| WAXWING | 266.8 | 135.0 | 7.50 | 142.5 | 18x3.09 | 1x3.09 | 15.45 | 421 | 30.3 | 0.210 |
| PARTRIDGE | 266.8 | 134.9 | 21.99 | 156.9 | 26x2.57 | 7x2.00 | 16.28 | 520 | 48.0 | 0.204 |
| OSTRICH | 300.0 | 152.2 | 24.71 | 176.9 | 26x2.73 | 7x2.12 | 17.28 | 584 | 54.0 | 0.180 |
| MERLIN | 336.4 | 170.2 | 9.46 | 179.7 | 18x3.47 | 1x3.47 | 17.35 | 532 | 38.0 | 0.166 |
| LINNET | 336.4 | 170.6 | 27.83 | 198.4 | 26x2.89 | 7x2.25 | 18.31 | 654 | 60.0 | 0.161 |
| ORIOLE | 336.4 | 170.5 | 39.78 | 210.3 | 30x2.69 | 7x2.69 | 18.83 | 736 | 74.5 | 0.158 |
| CHICKADEE | 397.5 | 200.9 | 11.16 | 212.1 | 18x3.77 | 1x3.77 | 18.85 | 628 | 43.5 | 0.141 |
| BRANT | 397.5 | 201.6 | 26.13 | 227.7 | 24x3.27 | 7x2.18 | 19.62 | 730 | 62.5 | 0.138 |
| IBIS | 397.5 | 201.3 | 32.73 | 234.1 | 26x3.14 | 7x2.44 | 19.88 | 773 | 70.2 | 0.136 |
| LARK | 397.5 | 200.9 | 46.88 | 247.8 | 30x2.92 | 7x2.92 | 20.44 | 869 | 87.3 | 0.134 |
