| Code | New Code | Al (mm²) | Steel (mm²) | Total (mm²) | No of Wires Al | No of Wires Steel | Wire Dia. Al (mm) | Wire Dia. Steel (mm) | Diameter Core (mm) | Diameter Cond (mm) | Mass per unit length (kg/km) | Rated Strength (kN) | DC Resistance (Ω/km) | Final modulus of elasticity (N/mm²) | Cofficient of linear expansion (1/K) | Direction of lay of external layer |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CANNA 37,7 | 28-AL1/9-ST1A | 28,3 | 9,42 | 37,7 | 9 | 3 | 2,00 | 2,00 | 4,30 | 8,3 | 152 | 16,26 | 0,1187 | 88000 | 1,71E-5 | S |
| CANNA 59,7 | 38-AL1/22-ST1A | 37,7 | 22,0 | 59,7 | 12 | 7 | 2,00 | 2,00 | 6,00 | 10,0 | 276 | 32,70 | 0,7660 | 103500 | 1,54E-5 | S |
| CANNA 75,5 | 48-AL1/28-ST1A | 47,7 | 27,8 | 75,5 | 12 | 7 | 2,25 | 2,25 | 6,75 | 11,3 | 349 | 41,15 | 0,6052 | 103500 | 1,54E-5 | S |
| CANNA 93,3 | 59-AL1/34-ST1A | 58,9 | 34,4 | 93,3 | 12 | 7 | 2,50 | 2,50 | 7,50 | 12,5 | 431 | 49,48 | 0,4902 | 103500 | 1,54E-5 | Z |
| CANNA 116,2 | 94-AL1/22-ST1A | 94,2 | 22,0 | 116,2 | 30 | 7 | 2,00 | 2,00 | 6,00 | 14,0 | 433 | 43,17 | 0,3067 | 75500 | 1,80E-5 | S |
| CANNA 147,1 | 119-AL1/28-ST1A | 119,3 | 27,8 | 147,1 | 30 | 7 | 2,25 | 2,25 | 6,75 | 15,8 | 547 | 54,03 | 0,2423 | 75500 | 1,80E-5 | S |
| CANNA 181,6 | 147-AL1/34-ST1A | 147,3 | 34,4 | 181,6 | 30 | 7 | 2,50 | 2,50 | 7,50 | 17,5 | 676 | 64,94 | 0,1963 | 75500 | 1,80E-5 | S |
| CANNA 228 | 185-AL1/43-ST1A | 184,7 | 43,1 | 227,8 | 30 | 7 | 2,80 | 2,80 | 8,40 | 19,6 | 848 | 80,54 | 0,1565 | 75500 | 1,80E-5 | S |
| CANNA 288 | 234-AL1/55-ST1A | 233,8 | 54,6 | 288,3 | 30 | 7 | 3,15 | 3,15 | 9,45 | 22,1 | 1073 | 98,58 | 0,1236 | 75500 | 1,80E-5 | S |
| Kod / Code | Al Alum. (mm²) | Çelik Steel (mm²) | Toplam Total (mm²) | Kompozisyon Al Alum. | Kompozisyon Çelik Steel | Çelik Öz Core (mm) | Toplam Total (mm) | Tensile S. fiber. Steel | Kopma Mukavemeti N Rated Stenght | Direnç Ω/km Electrical Resistance | Al Alum. (kg/km) | Çelik Steel (kg/km) | Toplam Total (kg/km) | Grease Weight Outside layer greased (g/m) | Grease Weight Outside layer ungreased (g/m) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CROCUS 297 | 221,7 | 75,5 | 297,2 | 36x2,80 | 19x2,25 | 11,3 | 156,8 | 156,8 | 14,7 | 0,131 | 594 | 624 | 1218 | 35 | 20 |
| CROCUS 412 | 325,7 | 86,0 | 411,7 | 32x3,60 | 19x2,40 | 12,0 | 156,8 | 156,8 | 17,3 | 0,090 | 676 | 917 | 1593 | 50 | 25 |
| CROCUS 612 | 507,8 | 104,7 | 611,8 | 66x3,13 | 19x2,65 | 13,3 | 156,8 | 156,8 | 23,2 | 0,057 | 824 | 1 | 2241 | 70 | 40 |
| CROCUS 865 | 717,3 | 148,1 | 865,4 | 66x3,72 | 19x3,15 | 15,8 | 156,8 | 156,8 | 31,9 | 0,041 | 1164 | 2010 | 3174 | 100 | 55 |
| CROCUS 1185 | 956,7 | 227,8 | 1184,5 | 54x2,80 + 66x3,47 | 37x2,80 | 19,6 | 44,7 | 156,8 | 48,1 | 0,030 | 1796 | 2682 | 4478 | 140 | 100 |
