| Code | AWG/MCM | Stranding Al | Stranding Steel | Section Al (mm²) | Section Total (mm²) | Diameter Total (mm) | Weight Total (kg/km) | Rated Strength (kN) | DC 20°C (Ω/km) | Current Capacity (A) |
|---|---|---|---|---|---|---|---|---|---|---|
| Turkey | 6 | 6×1.68 | 1×1.68 | 13.3 | 15.5 | 5.0 | 54 | 7.5 | 2.114 | 110 |
| Swan | 4 | 6×2.12 | 1×2.12 | 21.2 | 24.7 | 6.4 | 81 | 8.28 | 1.328 | 145 |
| Swanate | 4 | 7×1.96 | 1×2.61 | 21.1 | 26.5 | 6.5 | 100 | 10.50 | 1.131 | 145 |
| Sparrow | 2 | 6×2.67 | 1×2.67 | 33.6 | 39.2 | 8.0 | 136 | 12.68 | 0.834 | 195 |
| Sparate | 2 | 7×2.47 | 1×3.30 | 33.5 | 42.1 | 8.2 | 159 | 16.20 | 0.825 | 195 |
| Robin | 1 | 6×3.00 | 1×3.00 | 42.4 | 49.5 | 9.0 | 171 | 15.80 | 0.662 | 200 |
| Raven | 1/0 | 6×3.37 | 1×3.37 | 53.5 | 62.4 | 10.1 | 216 | 19.49 | 0.524 | 255 |
| Quail | 2/0 | 6×3.78 | 1×3.38 | 67.3 | 78.6 | 11.3 | 273 | 23.63 | 0.416 | 295 |
| Pigeon | 3/0 | 6×4.25 | 1×4.25 | 85.1 | 99.3 | 12.8 | 344 | 29.46 | 0.330 | 340 |
| Penguin | 4/0 | 6×4.77 | 1×4.77 | 107.2 | 125.1 | 14.3 | 433 | 37.16 | 0.261 | 390 |
| Waxwing | 266.8 | 18×3.09 | 1×3.09 | 135.0 | 142.5 | 15.5 | 323 | 30.62 | 0.212 | 480 |
| Partridge | 266.8 | 26×2.57 | 7×2.00 | 134.9 | 156.9 | 16.3 | 463 | 50.28 | 0.210 | 490 |
| Ostrich | 300 | 26×2.73 | 7×2.12 | 152.2 | 176.9 | 17.3 | 615 | 56.52 | 0.187 | 530 |
| Merlin | 336.4 | 18×3.47 | 1×3.47 | 170.2 | 179.7 | 17.4 | 543 | 38.36 | 0.168 | 560 |
| Linnet | 336.4 | 26×2.89 | 7×2.25 | 170.6 | 198.4 | 18.3 | 689 | 62.75 | 0.166 | 570 |
| Oriole | 336.4 | 30×2.69 | 7×2.69 | 170.5 | 210.3 | 18.8 | 784 | 76.98 | 0.165 | 575 |
| Chickadee | 397.5 | 18×3.77 | 1×3.77 | 200.9 | 212.1 | 18.9 | 643 | 44.23 | 0.122 | 620 |
| Brant | 397.5 | 24×3.27 | 7×2.18 | 201.6 | 227.7 | 19.6 | 762 | 64.97 | 0.142 | 630 |
| Ibis | 397.5 | 26×3.14 | 7×2.44 | 201.3 | 234.0 | 19.9 | 814 | 72.53 | 0.141 | 635 |
| Lark | 397.5 | 30×2.92 | 7×2.92 | 200.9 | 247.8 | 20.4 | 927 | 90.30 | 0.140 | 645 |
| Pelican | 477 | 18×4.14 | 1×4.14 | 242.3 | 255.8 | 20.7 | 771 | 52.51 | 0.118 | 700 |
| Flicker | 477 | 24×3.58 | 7×2.39 | 241.6 | 278.0 | 21.2 | 915 | 76.54 | 0.118 | 710 |
| Hawk | 477 | 26×3.44 | 7×2.67 | 241.8 | 280.8 | 21.8 | 978 | 86.77 | 0.117 | 715 |
| Hen | 477 | 30×3.20 | 7×3.20 | 241.3 | 297.6 | 22.4 | 1112 | 105.91 | 0.117 | 725 |
| Osprey | 556.5 | 18×4.47 | 1×4.47 | 282.5 | 298.2 | 22.4 | 899 | 60.96 | 0.101 | 775 |
| Parakeet | 556.5 | 24×3.87 | 7×2.58 | 282.3 | 318.9 | 23.2 | 1067 | 88.11 | 0.101 | 785 |
| Dove | 556.5 | 26×3.72 | 7×2.89 | 282.6 | 328.5 | 23.6 | 1140 | 105.57 | 0.101 | 790 |
| Eagle | 556.5 | 27×3.30 | 7×3.46 | 282.1 | 347.9 | 24.3 | 1298 | 123.71 | 0.100 | 800 |
| Peacock | 605 | 24×4.03 | 7×2.69 | 306.1 | 345.9 | 24.2 | 1161 | 96.12 | 0.093 | 830 |
| Squab | 605 | 26×3.87 | 7×3.01 | 305.8 | 355.6 | 24.5 | 1240 | 108.13 | 0.093 | 835 |
| Wooduck | 605 | 30×3.61 | 7×3.61 | 307.1 | 378.8 | 25.3 | 1411 | 128.60 | 0.092 | 845 |
| Teal | 605 | 30×3.61 | 19×2.16 | 307.1 | 376.1 | 25.2 | 1399 | 135.50 | 0.092 | 845 |
| Kingbird | 636 | 18×4.78 | 1×4.78 | 323.0 | 340.9 | 23.9 | 1027 | 69.83 | 0.089 | 845 |
| Rook | 636 | 24×4.14 | 7×2.76 | 323.1 | 365.0 | 24.8 | 1282 | 97.60 | 0.088 | 855 |
| Grosbeak | 636 | 26×3.97 | 7×3.09 | 321.8 | 374.4 | 25.2 | 1302 | 113.25 | 0.088 | 855 |
| Scoter | 636 | 30×3.70 | 7×3.70 | 322.6 | 397.9 | 25.9 | 1478 | 135.27 | 0.088 | 870 |
| Egret | 636 | 30×3.70 | 19×2.22 | 322.6 | 396.1 | 25.9 | 1470 | 140.17 | 0.088 | 870 |
| Swift | 636 | 36×3.38 | 1×3.38 | 323.0 | 332.0 | 23.7 | 958 | 61.41 | 0.089 | 845 |
| Flamingo | 666.6 | 24×4.23 | 7×2.82 | 337.3 | 381.0 | 25.4 | 1277 | 105.46 | 0.084 | 880 |
| Gannet | 666.6 | 26×4.07 | 7×3.16 | 338.3 | 393.2 | 25.8 | 1365 | 117.48 | 0.084 | 885 |
| Code | AWG/MCM | Stranding Al | Stranding Steel | Section Al (mm²) | Section Total (mm²) | Diameter Total (mm) | Weight Total (kg/km) | Rated Strength (kN) | DC 20°C (Ω/km) | Current Capacity (A) |
|---|---|---|---|---|---|---|---|---|---|---|
| Stilt | 715.5 | 24×4.39 | 7×2.92 | 363.3 | 410.2 | 26.3 | 1372 | 113.5 | 0.078 | 920 |
| Starling | 715.5 | 26×4.21 | 7×3.28 | 361.9 | 421.0 | 26.7 | 1466 | 126.4 | 0.078 | 930 |
| Redwing | 715.5 | 30×3.92 | 19×2.35 | 362.1 | 444.5 | 27.4 | 1653 | 154.0 | 0.078 | 940 |
| Cuckoo | 795.0 | 24×4.62 | 7×3.08 | 402.3 | 454.5 | 27.7 | 1522 | 124.2 | 0.071 | 985 |
| Drake | 795.0 | 26×4.44 | 7×3.45 | 402.6 | 468.0 | 28.1 | 1628 | 140.2 | 0.071 | 995 |
| Coot | 795.0 | 36×3.77 | 1×3.77 | 401.9 | 413.1 | 26.4 | 1198 | 74.8 | 0.072 | 975 |
| Tern | 795.0 | 45×3.38 | 7×2.25 | 403.8 | 431.6 | 27.0 | 1333 | 98.3 | 0.071 | 970 |
| Condor | 795.0 | 54×3.08 | 7×3.08 | 402.3 | 454.5 | 27.7 | 1514 | 125.5 | 0.071 | 975 |
| Mallard | 795.0 | 30×4.14 | 19×2.48 | 403.8 | 495.6 | 29.0 | 1838 | 170.9 | 0.070 | 1005 |
| Ruddy | 900.0 | 45×3.59 | 7×2.40 | 455.5 | 487.2 | 28.7 | 1511 | 108.6 | 0.062 | 1050 |
| Canary | 900.0 | 54×3.28 | 7×3.28 | 456.3 | 514.5 | 29.5 | 1725 | 142.0 | 0.062 | 1055 |
| Catbird | 954.0 | 36×4.14 | 1×4.14 | 484.6 | 498.1 | 29.0 | 1438 | 104.8 | 0.060 | 1095 |
| Rail | 954.0 | 45×3.70 | 7×2.47 | 483.8 | 517.3 | 29.6 | 1600 | 115.3 | 0.059 | 1090 |
| Cardinal | 954.0 | 54×3.38 | 7×3.38 | 484.5 | 547.3 | 30.4 | 1829 | 150.4 | 0.059 | 1095 |
| Tanager | 1033.5 | 36×4.30 | 1×4.30 | 522.8 | 537.3 | 30.1 | 1557 | 113.9 | 0.056 | 1130 |
| Ortolan | 1033.5 | 45×3.85 | 7×2.57 | 523.9 | 560.2 | 30.8 | 1734 | 123.3 | 0.055 | 1150 |
| Curlew | 1033.5 | 54×3.52 | 7×3.52 | 525.5 | 593.6 | 31.7 | 1981 | 162.9 | 0.054 | 1150 |
| Bluejay | 1113.0 | 45×4.00 | 7×2.66 | 565.5 | 604.4 | 32.0 | 1872 | 132.6 | 0.051 | 1125 |
| Finch | 1113.0 | 54×3.65 | 19×2.19 | 565.0 | 636.6 | 32.9 | 2130 | 174.0 | 0.051 | 1205 |
| Bunting | 1192.5 | 45×4.14 | 7×2.76 | 605.8 | 647.7 | 33.1 | 2000 | 142.4 | 0.048 | 1255 |
| Grackle | 1192.5 | 54×3.77 | 19×2.27 | 602.8 | 679.7 | 34.0 | 2281 | 186.5 | 0.047 | 1260 |
| Skylark | 1272.0 | 36×4.78 | 1×4.78 | 644.0 | 660.4 | 33.5 | 1917 | 117.5 | 0.045 | 1310 |
| Bittern | 1272.0 | 45×4.27 | 7×2.85 | 644.4 | 689.1 | 34.2 | 2134 | 151.7 | 0.045 | 1310 |
| Pheasant | 1272.0 | 54×3.90 | 19×2.34 | 645.1 | 726.8 | 35.1 | 2433 | 194.0 | 0.044 | 1310 |
| Dipper | 1351.5 | 45×4.40 | 7×2.92 | 684.2 | 731.4 | 35.2 | 2267 | 161.1 | 0.042 | 1360 |
| Martin | 1351.5 | 54×4.02 | 19×2.41 | 685.4 | 772.1 | 36.2 | 2585 | 206.0 | 0.042 | 1365 |
| Bobolink | 1431.0 | 45×4.53 | 7×3.02 | 725.3 | 775.4 | 36.2 | 2400 | 170.4 | 0.040 | 1410 |
| Plover | 1431.0 | 54×4.14 | 19×2.48 | 726.9 | 818.7 | 37.2 | 2738 | 218.5 | 0.039 | 1415 |
| Nuthatch | 1510.5 | 45×4.65 | 7×3.10 | 764.2 | 817.0 | 37.2 | 2533 | 178.4 | 0.037 | 1455 |
| Parrot | 1510.5 | 54×4.25 | 19×2.55 | 766.1 | 863.1 | 38.3 | 2890 | 230.1 | 0.037 | 1460 |
| Lapwing | 1590.0 | 45×4.78 | 7×3.18 | 807.5 | 863.1 | 38.2 | 2667 | 187.8 | 0.036 | 1505 |
| Falcon | 1590.0 | 54×4.36 | 19×2.62 | 806.2 | 908.6 | 39.3 | 3042 | 242.5 | 0.035 | 1510 |
| Chukar | 1780.0 | 84×3.70 | 19×2.22 | 903.8 | 976.7 | 42.7 | 3087 | 226.9 | 0.032 | 1620 |
| Bluebird | 2156.0 | 84×4.07 | 19×2.44 | 1092.8 | 1181.6 | 44.8 | 3738 | 268.3 | 0.026 | 1815 |
| Kiwi | 2167.0 | 72×4.41 | 7×2.94 | 1147.3 | 1203.4 | 44.1 | 3427 | 221.6 | 0.026 | 1795 |
| Thrasher | 2312.8 | 76×4.43 | 19×2.09 | 1171.4 | 1235.3 | 45.8 | 3761 | 252.3 | 0.025 | 1875 |
| Code | AWG/MCM | Stranding Al | Stranding Steel | Section Al (mm²) | Section Total (mm²) | Diameter Total (mm) | Weight Total (kg/km) | Rated Strength (kN) | DC 20°C (Ω/km) | Current Capacity (A) |
|---|---|---|---|---|---|---|---|---|---|---|
| Grouse | 8 | 8×2.54 | 1×4.24 | 40.5 | 54.7 | 9.3 | 222 | 23.14 | 0.680 | 200 |
| Petrel | 101.8 | 12×2.34 | 7×2.34 | 51.6 | 81.7 | 11.7 | 378 | 42.28 | 0.522 | 250 |
| Minorca | 110.8 | 12×2.44 | 7×2.44 | 56.1 | 88.8 | 12.2 | 412 | 50.28 | 0.479 | 265 |
| Leghorn | 134.6 | 12×2.69 | 7×2.69 | 68.2 | 108.0 | 13.5 | 500 | 60.52 | 0.395 | 300 |
| Guinea | 159.0 | 12×2.92 | 7×2.92 | 80.4 | 127.2 | 14.6 | 591 | 68.08 | 0.334 | 330 |
| Dotterel | 176.9 | 12×3.08 | 7×3.08 | 89.4 | 141.6 | 15.4 | 657 | 76.78 | 0.300 | 350 |
| Dorking | 190.8 | 12×3.20 | 7×3.20 | 96.5 | 152.8 | 16.0 | 709 | 83.21 | 0.278 | 370 |
| Brahma | 203.2 | 16×2.86 | 19×2.48 | 102.8 | 194.6 | 18.1 | 1007 | 126.37 | 0.252 | 380 |
| Cochin | 211.3 | 12×3.37 | 7×3.37 | 107.0 | 169.5 | 16.9 | 785 | 92.11 | 0.251 | 390 |
